The Class 150 Cast Steel Flanged, Three Piece Design Ball Valve comes with a sturdy body and is very smooth to use. The material used in manufacturing the Zoloto 80 mm Class 150 Cast Steel Flanged Three Piece Design Ball Valve is cast-steel for the corrosive free body and greater life expectancy. The 80 mm Class 150 Cast Steel Flanged Three Piece Design Ball Valve is free from corrosion and provides durability to the user. The size of the Ball Valve is 80 mm. In the Cast Steel Flanged, Three Piece Design Ball Valve end caps get welded to the pipe, and the main body section can get simply removed for cleaning or repair without the need to remove the end caps. The Three Piece Design Ball Valve has Flanged Ends to ANSI B16.5 Class-150 (Drilled). The Flanged Three Piece Design Ball Valve has a Seat (Steam) of 10.55 kg/cm²g (150 psig). The Ball Valve is suitable for water applications.
Product Specifications:
Brand: Zoloto
Made In: India
Design Standard: BS EN ISO 17292 (BS 5351)
Flanged Ends: ANSI B16.5 Class-150 (Drilled)
Maximum Temperature: 220°C
Model: 1089
Material: Cast Steel
Test Pressure(Hydrostatic): Shell: 31 kg/cm²g (440psig)
Seat: 21kg/cm²g (300 psig)
Seat (Steam): 10.55 kg/cm²g (150 psig)
Size: 80 mm
Suitable for: Water/Steam/Oil
Type: Flanged Three-Piece Design Ball Valve
Key Features:
Anti-Corrosion
Reliable
Long-Lasting
Easy Replace and Service
Two End Caps and a Body
Weld-in-Place End Caps
In-line Repair
Maximum Performance.
Premium Quality Product
