The Class 150 Cast Steel Flanged, Three Piece Design Ball Valve is wear-resistant not easy to damage during operation. The Zoloto 40 mm Class 150 Cast Steel Flanged Three Piece Design Ball Valve comes with a three-piece design. However, because pieces get replaced and serviced quickly and easily, the 40 mm Class 150 Cast Steel Flanged Three Piece Design Ball Valve is perfect for water, steam, and oil applications. The size of the Ball Valve is 40 mm. In the Cast Steel Flanged, Three Piece Design Ball Valve workpieces of various forms using a high-precision non-slip design with long service life. The Three Piece Design Ball Valve has Flanged Ends to ANSI B16.5 Class-150 (Drilled). In addition, the Flanged Three Piece Design Ball Valve has a design standard of BS EN ISO 17292 (BS 5351). The Ball Valve comes with Weld-in-Place End Caps.
Product Specifications:
Brand: Zoloto
Made In: India
Design Standard: BS EN ISO 17292 (BS 5351)
Flanged Ends: ANSI B16.5 Class-150 (Drilled)
Maximum Temperature: 220°C
Model: 1089
Material: Cast Steel
Test Pressure(Hydrostatic): Shell: 31 kg/cm²g (440psig)
Seat: 21kg/cm²g (300 psig)
Seat (Steam): 10.55 kg/cm²g (150 psig)
Size: 40 mm
Suitable for: Water/Steam/Oil
Type: Flanged Three-Piece Design Ball Valve
Key Features:
Three Piece Design
Reliable
Long-Lasting
Easy Replace and Service
Two End Caps and a Body
Weld-in-Place End Caps
In-line Repair
Maximum Performance.
Suitable for water
