The 32 mm Class 150 Cast Steel Flanged Three Piece Design Ball Valve is one of the indispensable devices manufactured by Zoloto. This Class 150 Cast Steel Flanged Three Piece Design Ball Valve is composed of a top-notch quality cast iron material that is great at withstanding varying flow rates, pressures, and temperatures. Therefore, this Zoloto- 32 mm Class 150 Cast Steel Flanged Three Piece Design Ball Valve is highly suitable for conditions with high demand on the ball valve. In addition, Flanged Three Piece Design Ball Valve, featuring two end caps and one body, delivers exceptional performance.
Product Specifications:
Manufactured by: Zoloto
Model: 1089
Material: Cast Iron
Size: 32 mm
Class: 150
Suitable for: Steam, Water and Oil
Test Pressure (Hydrostatic): Shell: 31 kg/cm²g (440psig)
Seat: 21kg/cm²g (300 psig)
Seat (Steam): 10.55 kg/cm²g (150 psig)
Maximum Working Temperature: 220°C
Key Features:
Flanged Three Piece Design Ball Valve
Deliver outstanding performance in conditions with high demand for the valve.
Composed of top-notch quality cast iron.
