Zoloto 1089 - 25 mm Class 150 Cast Steel Flanged Three Piece Design Ball Valve


Available on Request
Quantity
Minimum Order Quantity: 1 unit(s) Packing Qty: 1 Piece
OR
Reach Us At +91-9243011081

Zoloto 1089 - 25 mm Class 150 Cast Steel Flanged Three Piece Design Ball Valve

Price

Available on Request
Delivery * Free delivery above Rs. 1000
* COD payment upto Rs. 5000
* 7 days easy replacement policy
* Bulk orders are shipped through surface and therefore might take more than 10 days for delivery

Check

Please enter pincode.
Services

Dispatch in 2-3 Business Days

Standard SD Replacement Policy

100% Authentic and Genuine Products. Secure and Safe Payments.

NA

NA

Description

In high-cycle and high-pressure applications, the Zoloto 25 mm Class 150 Cast Steel Flanged Three Piece Design Ball Valve components get subjected to a tremendous degree of wear and tear. The 25 mm Class 150 Cast Steel Flanged Three Piece Design Ball Valve is perfect for water, steam, and oil applications. The Class 150 Cast Steel Flanged, Three Piece Design Ball Valve is manufactured with cast steel to ensure a strong core and rigid body for heavy applications. In the Cast Steel Flanged, Three Piece Design Ball Valve end caps get welded to the pipe, and the main body section can get simply removed for cleaning or repair without the need to remove the end caps. The Three Piece Design Ball Valve has Flanged Ends to ANSI B16.5 Class-150 (Drilled). In addition, the Flanged Three Piece Design Ball Valve has a design standard of BS EN ISO 17292 (BS 5351). The maximum temperature a Ball Valve can handle is 220°C.
Product Specifications:
Brand: Zoloto
Made In: India
Design Standard: BS EN ISO 17292 (BS 5351)
Flanged Ends: ANSI B16.5 Class-150 (Drilled)
Maximum Temperature: 220°C
Model: 1089
Material: Cast Steel
Test Pressure(Hydrostatic): Shell: 31 kg/cm²g (440psig)
Seat: 21kg/cm²g (300 psig)
Seat (Steam): 10.55 kg/cm²g (150 psig)
Size: 25 mm
Suitable for: Water/Steam/Oil
Type: Flanged Three-Piece Design Ball Valve
Key Features:
Three Piece Design
Convenient to Use
Easy Replace and Service
Two End Caps and a Body
Weld-in-Place End Caps
In-line Repair
Premium in Quality and Performance.
Suitable for water

Product Specifications

GENERAL

Brand:
Zoloto
Material:
Cast Steel
Model:
1089
Product:
Flanged Three Piece Design Ball Valve
Size:
25 mm
