For those seeking an ideal Flanged Three Piece Design Ball Valve for high-pressure applications, the 100 mm Class 150 Cast Steel Flanged Three Piece Design Ball Valve from Zoloto is a suitable option. The Class 150 Cast Steel Flanged Three Piece Design Ball Valve is a fantastic tool for processes and applications where valves can provide optimum performance. Elastomers can also change to accommodate different process conditions, flows, pressures, and temperatures with this Zoloto - 100 mm Class 150 Cast Steel Flanged Three Piece Design Ball Valve. In addition, this Three Piece Design Ball Valve offers the flexibility to remove the body without disturbing both end caps. This Ball Valve is full of flexibility, durability, and versatility.
Product Specifications:
Manufactured by: Zoloto
Model: 1089
Material: Cast Iron
Size: 100 mm
Class: 150
Suitable for: Steam, Water and Oil
Test Pressure (Hydrostatic): Shell: 31 kg/cm²g (440psig)
Seat: 21kg/cm²g (300 psig)
Seat (Steam): 10.55 kg/cm²g (150 psig)
Maximum Working Temperature: 220°C
Key Features:
Flexible, durable, and versatile tool.
Composed of solid cast iron material.
Highly rigid and effective
