Zoloto 1083A - 125 mm PN 1.6 Cast Iron Flanged Non Return Valve


Available on Request
Quantity
Minimum Order Quantity: 1 unit(s) Packing Qty: 1 Piece
OR
Reach Us At +91-9243011081
Zoloto

Zoloto 1083A - 125 mm PN 1.6 Cast Iron Flanged Non Return Valve

Price

Available on Request
Delivery * Free delivery above Rs. 1000
* COD payment upto Rs. 5000
* 7 days easy replacement policy
* Bulk orders are shipped through surface and therefore might take more than 10 days for delivery

Check

Please enter pincode.
Services

Dispatch in 2-3 Business Days

Standard SD Replacement Policy

100% Authentic and Genuine Products. Secure and Safe Payments.

NA

NA

Description

The Flanged Non-Return Valve is a safety-critical valve that protects the system and its components from harm that can vary from increased wear and tear to full, catastrophic system failure depending on the degree of the system design. The cracking pressure, the lowest difference upstream pressure between the intake and exit at which the valve will operate, is an essential concept in Zoloto 125 mm PN 1.6 Cast Iron Flanged Non-Return Valve. The 125 mm PN 1.6 Cast Iron Flanged Non-Return Valve has an iron cast cover and body. The Flanged Non-Return Valve is a multi-purpose product. The Cast Iron Flanged Non-Return Valve has a renewable seat with a top-quality rubber flap. The Size of the Flanged Non-Return Valve is 125 mm. The Non-Return Valve is a check valve in which the disc, the moveable element that blocks the flow, swings on a hinge or trunnion, either onto or off the seat to allow forward flow or onto the seat to restrict reverse flow.
Product Specifications:
Brand: Zoloto
Made In: India
Maximum Temperature: 80°C
Material: Cover: Cast Iron
Gasket: Nitrile Rubber
Body: Cast Iron
Hinge Pin: Stainless Steel
Body Seat Ring: Bronze / Stainless Steel
Model: 1083A
Seating Design: Swing Type
End Connection: Flanged
Media: Water
Colour: Black
Size: 125 mm
Design Standard: IS 5312-1
Type: Non-Return Valve
Origin: India
Key Features:
Corrosion Free
Durable
Black Finish
Seat Test Pressure (Hydrostatic) 1.0 MPa
Bolted Cover
Swing Type Seating
Prevent Reverse Flow

Product Specifications

GENERAL

Brand:
Zoloto
Material:
Cast Iron
Model:
1083A
Product:
Flanged Non Return Valve
Size:
125 mm
