Zoloto 1078K - 40 mm, PN 1.6, Wafer Type Butterfly Valve with Electrical Actuator


Available on Request
Quantity
Minimum Order Quantity: 1 unit(s) Packing Qty: 1 Piece
OR
Reach Us At +91-9243011081

Zoloto 1078K - 40 mm, PN 1.6, Wafer Type Butterfly Valve with Electrical Actuator

Price

Available on Request
Delivery * Free delivery above Rs. 1000
* COD payment upto Rs. 5000
* 7 days easy replacement policy
* Bulk orders are shipped through surface and therefore might take more than 10 days for delivery

Check

Please enter pincode.
Services

Dispatch in 2-3 days

Standard SD Replacement Policy

100% Authentic and Genuine Products. Secure and Safe Payments.

NA

NA

Description

Design Standard IS 13095 / BS EN 593 (BS 5155). Wafer Type. Electrical Acuator Operated. S.G Iron construction. Stainless Steel (CF8 / CF8M*) Disc which is accurately guided between the two stems. Actuator is with position indicator and adjustable center stopper for both open and closed position. Compliant with B.M.S (Building Management System). Can be provided with extended wire for ease of installation. IP 67 protection available for outdoor application. Inbuilt micro switch position feedback. Input Voltage - 24/230 V power supply. Integrally moulded rubber lining (EPDM / Nitrile / Neoprene* / Viton* / Silicon*) as per requirement which provides seating to the valve disc, as a primary seal to the stem and gasket joint with matching pipe flanges. Two Piece Stem design which is precisely guided between the PTFE / Bronze bushes. Compatible to sandwich between flanges as per BS 10 Table D, E, F,H, DIN, PN 10, PN 16, PN 25, PN 40, ASA 150, ASA 300, IS 778, IS 6392 Table 17 and IS 1538.

Product Specifications

GENERAL

Brand:
Zoloto
Country of Origin:
India
Material:
SG Iron
Model Number:
1078K
Seat Test Pressure:
1.76 MPa
Size:
40 mm
Voltage:
230V
