The Zoloto - 300 mm Wafer Type, Butterfly Valve with SG Iron Disc is a lever-operated butterfly valve designed to fit two flanges in the pipework. The 300 mm Wafer Type, Butterfly Valve with SG Iron Disc is constructed from high-grade Cast Iron. The Wafer Type, Butterfly Valve with SG Iron Disc, is designed according to IS 13095/BS EN 593 ( BS 5155) standards. The Butterfly Valve with S G Iron Disc has a moulded rubber lining that seals the stem and gasket juncture with the matching pipe flanges. The Butterfly Valve has a maximum working temperature of 90 deg C and a maximum working pressure of 2.5 MPa.
Product Specifications:
Brand: Zoloto
Product: Butterfly Valve
Size: 300mm
Type: Wafer
Material: S.G Iron
Weight: 1.4 kg
Maximum Working Pressure: 2.5 MPa
Maximum Working Temperature: 90 degrees C
Key Features:
Suitable for use with water
Easy installation
Quick opening and closing
