Veritek VIPS 80EL C - 1 Phase Multifunctional LCD Power Analyzer Meter


Available on Request
Quantity
Minimum Order Quantity: 1 unit(s) Packing Qty: 1 Piece
OR
Reach Us At +91-9243011081

Veritek VIPS 80EL C - 1 Phase Multifunctional LCD Power Analyzer Meter

Price

Available on Request
Delivery * Free delivery above Rs. 1000
* COD payment upto Rs. 5000
* 7 days easy replacement policy
* Bulk orders are shipped through surface and therefore might take more than 10 days for delivery

Check

Please enter pincode.
Services

Dispatch in 2-3 Business Days

Standard SD Replacement Policy

100% Authentic and Genuine Products. Secure and Safe Payments.

NA

NA

Description

The Veritek VIPS 80EL C1 LCD power analyzer is a multifunctional meter and assists in several uses as the name suggests. It is specially designed for detection of electricity in various fields such as mining, infrastructure. It comes from a class of Power & Energy Meters that is manufactured with an LCD backlight and consists of the main material as ABS Thermoplastic. The Veritek Multifunctional LCD Power Analyzer Meter has a flash mounting with side clamp. Project owners use it for measuring parameters on electrical networks such as voltage, powers – reactive & active, frequencies, energies, etc. It is a useful tool in many intelligent systems such as energy management systems, SCADA.

Product Attributes:

  • AC Voltage : 0-500 V AC
  • Accuracy Class: +/- 0.5%
  • Auxiliary Power Supply: 90-270 V, +/- 15 %
  • Current measurement: 0-5 Amp
  • Digit: 4 rows of 4 digits for Parameter, 4 rows of 8 digits for Energy
  • Dimensions: 96x92x55 mm
  • Frequency Measurement: 50-60 Hz
  • Operating temperature: -10 to 55 Degree ( in Celsius)
  • Voltage Measurement: 0-300 V
  • Weight: 280 grams

Benefits:

  • Site programmable as CT & PT Ratio
  • Relays output as per maximum demand
  • Auto ranging
  • Has password protection so very secure
  • Harmonic measurement – Total & Individual
  • Universal Auxiliary supply
Product Specifications

GENERAL

AC voltage:
0-500 V AC
Accuracy Class:
+/- 0.5 Percent
Auxiliary Power Supply:
90-270 V, +/- 15 Percent
Brand:
Veritek
Current measurement:
0-5 Amp
Digit:
4 rows of 4 digits for Parameter, 4 rows of 8 digits for Energy
Dimensions:
96x92x55 mm
Display:
LCD Display with Backlight
Frequency Measurement:
50-60 Hz
Manufacturer Details:
Veritek Engineering Pvt. Ltd., Plot No. 222, EL - Electronic Zone, T.T.C. Industrial Area, M.I.D.C., Mahape, Thane, Maharashtra-400701, India, Phone: +91-8448233444
Material:
ABS Thermoplastic
Model:
VIPS 80EL-C
Mount:
Flush Mounting with Side Clamp
Operating temperature:
-10 to 55 Deg C
Packer Details:
Veritek Engineering Pvt. Ltd., Plot No. 222, EL - Electronic Zone, T.T.C. Industrial Area, M.I.D.C., Mahape, Thane, Maharashtra-400701, India, Phone: +91-8448233444
Voltage Measurement:
0-300 V
Weight:
280 grams
