Description

V Guard VOS F90 - 1 HP Openwell Submersible Pump - V Guard open well submersible pump is designed for lifting the water from underground tanks and wells. It is engineered with a unique design to work efficiently and last for a longer time. It is a form of smooth and silent solution to the modern household. Few of its features include a long-lasting device, light in weight and comes in a compact size. There is a stainless steel insert provided in casing and adaptor. 1 HP submersible pump has high quality and long life mechanical seal with a thermal overload protector. V guard pump operates on an aluminium pressure die-cast motor body.

Product Attributes:

  • Body: Stainless motor body with anti corrosive primer coating
  • Insulation: Class B
  • Bearings: Water Lubricated thrust and bush bearings made out of Leaded Tin bronze (LTB)
  • Impeller: Dynamically balanced Centrifugal radial flow type
  • Motor Shaft: ANSI 410 Stainless Steel Shaft
  • Direction of rotation: Anti clock wise, when viewed from suction Side
Product Specifications

GENERAL

Brand:
V-Guard
Country of Origin:
India
Duty Type:
Continious S1
Head vs Discharge at 1 HP:
12 M: 10100 LPH, 15 M: 9500 LPH, 18 M: 7500 LPH, 21 M: 5300 LPH, 24 M: 3600 LPH, 27 M: 3450 LPH
Model:
VOS F90
Phase:
Single Phase
Pipe Size:
3.2x2.5 cm
Power:
1 HP, 0.75 Kw
Series:
VOS Series
Speed:
2800 RPM
Voltage range:
180 - 240 V
