V Guard VCTW 100 - 2 HP Single Phase Centrifugal Pump


Available on Request
Quantity
Minimum Order Quantity: 1 unit(s) Packing Qty: 1 Piece
OR
Reach Us At +91-9243011081

V Guard VCTW 100 - 2 HP Single Phase Centrifugal Pump

Price

Available on Request
Delivery * Free delivery above Rs. 1000
* COD payment upto Rs. 5000
* 7 days easy replacement policy
* Bulk orders are shipped through surface and therefore might take more than 10 days for delivery

Check

Please enter pincode.
Services

Dispatch in 2-3 Business Days

Standard SD Replacement Policy

100% Authentic and Genuine Products. Secure and Safe Payments.

NA

NA

Description

Features:

  • Body: Rigid Cast Iron/Aluminum motor body
  • Insulation: Class 'B'
  • Motor shaft: High quality Alloy Steel
  • Mechanical seal: High quality mechanical seal with Graphite face
  • Impeller: Centrifugal radial flow
  • Motor: The pumps are coupled to high efficient V-Guard induction motors. The motors are Totally Enclosed Fan Cooled (TEFC), capacitor start and run type. Also equipped with overall load protector (TOP) to avoid coil burn out. Using 99.9% pure super enamel
  • Bearings: Double sealed ball bearings with lubrication
  • Direction of rotation: Clockwise, when viewed from motor side
Product Specifications

GENERAL

Brand:
V-Guard
Capacitor:
75 mfd
Country of Origin:
India
Duty Type:
Continious S1
Head vs Discharge at 2 HP:
15 M: 415 LPH, 18 M: 395 LPH, 21 M: 380 LPH, 24 M: 360 LPH, 27 M: 300 LPH, 30 M: 190 LPH
Model:
VCTW 100
Phase:
Single Phase
Pipe Size:
50x40 mm
Power:
2 HP, 1.5 Kw
Rated Current:
14.0 A
Speed:
2800 RPM
Voltage range:
180- 240 V
