Description

Features:

  • High-Quality electrical grade stamping used as motor core
  • Special LTB bushes inside the motor for higher wear resistance and longer life
  • Specially designed Pressure diaphragm to compensate thermal expansion
  • High quality Carbon impregnated Teflon/Carbon thrust pad with cast iron/SS base
  • Maximum total head: 408 meters (1338 feet)
  • Rewindable squirrel cage water cooled electric motor as prime mover
  • Copper winding wire with high quality triple layer BOPP insulation wrapping
  • High-quality Dual seal protection with specially designed rubber + SS sand guard to prevent sand entry
  • Combination of special LTB and Rubber bushes in pump side
  • High grade cast iron/ SS made diffusers and housings
Product Specifications

GENERAL

Brand:
V-Guard
Country of Origin:
India
Head vs Discharge at 10 HP:
420 M: 30 LPM, 390 M: 44 LPM, 360 M: 60 LPM, 330 M: 70 LPM, 300 M: 80 LPM, 270 M: 90 LPM, 240 M: 96 LPM, 210 M: 100 LPM, 0 M: 106 L
Model:
VBTC 10010
No of Stages:
10
Pipe Size:
50 mm
Power:
10.0 HP, 7.5 Kw
Rated Current:
19 A
Series:
VBTC Series 1
