Buy V-Guard VBSO F150 10 - 1 HP Oil Filled Submersible Pump Online

V-Guard VBSO F150 10 - 1 HP Oil Filled Submersible Pump


Available on Request
Quantity
Minimum Order Quantity: 1 unit(s) Packing Qty: 1 Piece
OR
Reach Us At +91-9243011081

V-Guard VBSO F150 10 - 1 HP Oil Filled Submersible Pump

Price

Available on Request
Delivery * Free delivery above Rs. 1000
* COD payment upto Rs. 5000
* 7 days easy replacement policy
* Bulk orders are shipped through surface and therefore might take more than 10 days for delivery

Check

Please enter pincode.
Services

Dispatch in 1-2 Business Days

Standard SD Replacement Policy

100% Authentic and Genuine Products. Secure and Safe Payments.

NA

NA

Description

V-Guard VBSO F150 10 - 1 HP Oil Filled Submersible Pump serves different water requirements at agricultural, industrial, and domestic levels. The 1 HP Oil-Filled Submersible Pump is thermally protected built-in to keep the motor from overheating. Stainless steel is used for both the pump-priming and the motor. The oil-filled submersible pump can be an ideal choice for wide voltage fluctuations. The small size of the submersible pump makes it easy to install and transport from one location to another. The body is composed of stainless steel that is closed. Oil seals prevent silt from entering the system. The thrust bearings are easily able to absorb the axial thrust generated by the pump. Ideal for both water and oil-filled engines.

Product Specifications:

  • Brand: V-Guard
  • Model: VBSO F150
  • Power Rating: 075kW
  • Insulation: Class B
  • Speed: 2800rpm
  • Phase: Single Phase
  • Installation Type: Vertical
  • Head Range: 35-60 m
  • Pipe Size: 3.2 cm
  • Rated Voltage: 180-240V
  • Start Capacitor: 100-120 mF
  • Motor Power: 1HP
  • Frequency: 50Hz

Key Power:

  • Stainless Steel
  • Axial Thrust
  • Oil-filled
Product Specifications

GENERAL

Brand:
V-Guard
Capacitor:
36 mfd
Country of Origin:
India
Customer Care Number:
1800-103-1300
Frequency:
50 Hz
Head Range:
35-60 m
Installation Type:
Vertical
Insulation:
Insulation
Model:
VBSO F150 10
No Load Speed:
2800 RPM
Notes:
Actual product model might vary from that shown in the picture
Phase:
Single Phase
Pipe Size:
3.2 cm
Power:
1 HP, 0.75 kW
Rated Voltage:
180-240 V
Series:
VBSO
Start Capacitor:
100/120 mfd
Total Head:
196 ft
Warranty:
1 Year Onsite Warranty
