Description

Features:

  • Body: Rigid Cast Iron motor body
  • Insulation: Class 'B'
  • Bearings: Double sealed ball bearings with life lubrication
  • Motor shaft: High quality Alloy Steel
  • Motor: The pumps are coupled to high efficient V-Guard induction motors. The motors are Totally Enclosed Fan Cooled (TEFC), capacitor start, capacitor run type. Also equipped with Thermal Overload Protector (TOP) to avoid coil burn out
  • Direction of Rotation: Clockwise, when viewed from motor side
Product Specifications

GENERAL

Air Pipe Size:
12 mm
Belt:
A 38
Brand:
V-Guard
Compressor Water Lifting Height Vs Discharge:
225 Mtrs: 900 LPH
Country of Origin:
India
Duty Type:
Continious S1
Model:
VBC F400
Operating Pressure:
7 Kg/cm2
Phase:
Single Phase
Power:
1 HP, 0.75 Kw
Pumping Height:
75 Mtrs
Series:
VBCM Series
Speed:
1200 RPM
Total Depth:
300 Mtrs
Voltage range:
180- 240 V
Water Pipe Size:
25 mm
Weight:
29 Kg
