Buy V Guard Neon JF100BWP - 1 HP Neon Series Single Phase Jet Centrifugal Pump Online

V Guard Neon JF100BWP - 1 HP Neon Series Single Phase Jet Centrifugal Pump


Available on Request
Quantity
Minimum Order Quantity: 1 unit(s) Packing Qty: 1 Piece
OR
Reach Us At +91-9243011081

V Guard Neon JF100BWP - 1 HP Neon Series Single Phase Jet Centrifugal Pump

Price

Available on Request
Delivery * Free delivery above Rs. 1000
* COD payment upto Rs. 5000
* 7 days easy replacement policy
* Bulk orders are shipped through surface and therefore might take more than 10 days for delivery

Check

Please enter pincode.
Services

Dispatch in 2-3 Business Days

Standard SD Replacement Policy

100% Authentic and Genuine Products. Secure and Safe Payments.

NA

NA

Description

Features:

  • Body: Aluminum motor body
  • Motor shaft: High quality Alloy Steel
  • Motor: The pumps are coupled to high efficient V-Guard induction motors. The motors are Totally Enclosed Fan Cooled (TEFC), capacitor start and run type. Also equipped with Overload Protector (TOP) to avoid coil burn out using 99.99% pure super enameled C
  • Mechanical seal: High quality mechanical seal with Graphite face
  • Impeller: Centrifugal radial flow type
  • Insulation: Class'B'
  • Bearings: Double sealed ball bearings with lubrication
  • Direction of rotation: Clockwise, when viewed from motor side
Product Specifications

GENERAL

Brand:
V-Guard
Capacitor:
25 mfd
Country of Origin:
India
Duty Type:
Continious S1
Head vs Discharge at 1 HP:
9 M: 1150 LPH, 12 M: 1025 LPH, 15 M: 975 LPH, 18 M: 925 LPH, 21 M: 825 LPH, 24 M: 750 LPH, 27 M: 600 LPH, 30 M: 500 LPH
Model:
Neon JF100BWP
Phase:
Single Phase
Pipe Size:
3.2x2.5x2.5 cm
Power:
1 HP, 0.75 Kw
Series:
Neon Series
Speed:
2800 RPM
Voltage range:
180- 240 V
