Certification:
CE, FCC, RoHS
Dimensions:
226 ? 131 ? 35 mm
Environment:
Operating Temperature: 0?40 ? (32?104 ?), Storage Temperature: -40?70 ? (-40?158 ?),Operating Humidity: 10?90% RH non-condensing, Storage Humidity: 5?90% RH non-condensing
Flash:
SPI 4MB + NAND 128MB
Interface:
1 Fixed Gigabit SFP WAN Port, 1 Fixed Gigabit RJ45 WAN Port, 2 Fixed Gigabit RJ45 LAN Ports, 2 Changeable Gigabit RJ45 WAN/LAN Ports
LED:
PWR, SYS, SFP WAN, WAN (Speed, Link/Act), LAN (Speed, Link/Act)
Network Media:
10BASE-T: UTP category 3, 4, 5 cable (Max 100m) EIA/TIA-568 100ê STP (Max 100m), 100BASE-TX: UTP category 5, 5e cable (Max 100m) EIA/TIA-568 100ê STP (Max 100m), 1000BASE-T: UTP category 5, 5e, 6 cable (Max 100m)
Package Contents:
ER7206, Power Cord, Quick Installation Guide
Power Supply:
100?240 V~50/60 Hz
Security:
SPI Firewall, VPN Passthrough, FTP/H.323/PPTP/SIP/IPsec ALG, DoS Defence, Ping of Death, Local Management
Standards and Protocols:
IEEE 802.3, IEEE802.3u, IEEE802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1q, TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, SNMP
System Requirements:
Microsoft Windows 98SE, NT, 2000, XP, Vista? or Windows 7/8/8.1/10, MAC OS, NetWare, UNIX or Linux
