Antenna Type:
Gain: 23 dBi & Beamwidth: 9 deg, Azimuth, 7 deg Elevation
Certification:
CE, FCC, UL, IC, GS, PSB, C-tick, SAA, S-Mark & KC-mark, CE, FCC, IC, RoHS & IP65
Colour:
Power Status LEDs: Green
Configuration:
Network: WAN: Static, Dynamic, PPPoE, L2TP, PPTP, LAN: Static, Dynamic, DHCP, Forwarding: ALG, UPnP, Virtual Server, Port Trigger, Security: SPI Firewall, Ping Forbidden, DoS Protection, Access Control & Static Routing, Bandwidth Control, IP & MAC Binding
Dimensions:
366x280x207 mm, POE Adapter: 85.8x43.9x29.7 mm
Enclosure:
Material: Outdoor PC Stabilized Plastic & Weatherproof: IP65 Water & Dust Proof Design
Input:
100-240 V AC & 50-60 Hz
Interface:
1 10, 100 Mbps Shielded Ethernet Port & 1 Reset Button, POE adapter: 1 AC Jack with Earth Ground, 1 10, 100 Mbps Shielded Ethernet Port & 1 10, 100 Mbps Shielded Ethernet Port
Memory:
64 MB DDR2 RAM & 8 MB Flash
Number of Buttons:
Remote Reset Button
Operating Humidity:
10-90% (Non-Condensing)
Operating temperature:
0 to 40 deg C
Output:
24 V DC, 0.5 Amp Max & +4, 5 Pins & -7, 8 Pins
Package Contents:
Outdoor Wireless CPE, 24 V 0.5 Amp Passive POE Adapter, Pole Mounting Straps, AC Power Cord & Installation Guide
Power Supply:
Passive Power over Ethernet via LAN, 16-27 V DC
Power Transmission:
Max. 25 dBm
Processor:
Qualcomm 560MHz CPU & MIPS 74KC
Protection:
15 kV ESD Protection & 6 kV Lightning Protection
Protocol:
Proprietary: TDMA Mode
Remote Management Protocol:
Discovery & Remote Management via Pharos Control application, HTTP/HTTPS Web-Based Management, System Log, SNMP Agent, Ping Watch Dog, Dynamic DDNS & SSH Server
Speed:
Wireless: Upto 300 Mbps, Upto 144.4 Mbps, Upto 72.2 Mbps & Upto 36.1 Mbps
Storage Humidity:
5-90% (Non-Condensing)
Storage Temperature:
-40 to 70 deg C
System:
Tools: Wireless Signal Quality Indicators, Signal Strength, Noise, Transmit CCQ, CPU, Memory, Monitors: Throughput, Stations, Interfaces, ARP, Routes, WAN, DHCP, Spectrum Analyzer, Speed Test, Ping & Traceroute
System Requirements:
Windows: 98SE, NT, 2000, XP, Vista or Windows 10, Windows 8, Windows 7, MAC OS, NetWare & UNIX or Linux
Wireless:
Wireless: IEEE 802.11a/n
