Description
APPLICATIONS
  • "TANCO" High Temperature Muffle Furnace is elegantly designed in various applications for Educational R&D labs, Chemical, Pharma, Steel Industries & Foundries & Treatment of samples under high temperature.
  • Low Cost option for heating the material on high temperature.
SALIENT FEATURES & CONSTRUCTION
  • Floor Model Type.
  • Heating by Imported Silicon Carbide Rods.
  • Thermal loss is prevented by ceramic fiber insulation in space between the outer body & heating chamber.
  • Easily Replaceable Carbide Rods.
  • Saves Energy upto 30%.
  • Outstanding Temperature Reliability.
  • Having large surface radiation ratio to enhance thermal efficiency and power consumption.
  • Duly controlled by Accurate step down Transformer (Air Cooled).
  • Chamber made of Ceramic Zirconium Board.
  • Fitted with heavy hinges & door is duly insulated.
  • Elements are placed horizontally in the chamber.
  • Fitted with thermocouple & silver fuse for protection of chamber.
  • Control panel fitted with Digital Temperature Indicator cum Controller upto 16000C with sensor & AMP Meters.
  • Temperature is controlled by electronic digital temperature indicator cum controller from 100°C to 1450°C, + 50C fitted on the front panel for easy operations.
  • Temperature is displayed by Digital LED with SV and PV display at front of the Furnace (Optional).
  • Operating Voltage: 220 Volts AC (50 Hz).
Product Specifications

GENERAL

Brand:
Tanco
Inner Chamber:
200 X 200 X 300 mm
Model:
MFH-4
Rating:
7 Kw
Supply Voltage:
220V, 50Hz
