The Siemens - 3NE3 type 1000 V AC Fuse for semiconductor protection SITOR 3NE / 3NC helps in partial range breaking capacity fuse for the short circuit protection of semiconductor devices. The 1000 V AC Fuse for semiconductor protection SITOR 3NE / 3NC has a sturdy build. The 1000 V AC Fuse provides good performance while being small, easy to install, and safe for the operator. The 1000 V AC Fuse complies with the industrial standards for universal acceptability and safety. In addition, the 1000 V AC Fuse works significantly faster than traditional low voltage high resistance fuses. SITOR semiconductor fuses feature a high variable load factor, making them ideal for high-voltage applications. Besides, the rigorous quality standards ensure that the AC Fuse meets all regulatory requirements.
Product Specifications:
Manufactured By: Siemens
DIN size: 2
Model: 3NE3335
Rated Current: 630 A
Rated Voltage: 1000 V AC
Utilisation category: aR
Melting I2t value I2ta: 66500 A2s
Breaking I2t value I2ta at Un: 60000 A2s
Temperature rise at In body centre: 120 K
Power Dissipation at In: 95 W
Key Features:
It has a high rated breaking capacity
It is durable
