A fuse is an electrical safety device protecting an electrical circuit against overcurrent damage. Its primary component is a metal wire or strip that melts when an excessive current travels through it, effectively interrupting or stopping the current. Similarly, the Siemens - 3NE3 type 1000 V AC Fuse for semiconductor protection SITOR 3NE / 3NC prevents semiconductors from short circuits. The AC Fuse for semiconductor protection SITOR 3NE / 3NC has a voltage rate of 1000 V. The AC Fuse are current-limiting fuses that are extremely quick-acting and have low melting integral values and low peak let-through currents. As a result, the AC Fuse is durable and works great. Moreover, the 1000 V AC Fuse works significantly faster than traditional low voltage high resistance fuses.
Product Specifications:
Manufactured By: Siemens
DIN size: 1
Model: 3NE32300B
Rated Current: 350 A
Rated Voltage: 1000 V AC
Utilisation category: aR
Melting I2t value I2ta: 13400 A2s
Breaking I2t value I2ta at Un: 80000 A2s
Temperature rise at In body centre: 100 K
Power Dissipation at In: 60 W
Key Features:
It has a high rated breaking capacity
It adheres to industrial standards
