Buy Sanwa HG561H - 500 V Hybrid M Clamp Meter Online

Sanwa HG561H - 500 V Hybrid M Clamp Meter


Available on Request
Quantity
Minimum Order Quantity: 1 unit(s) Packing Qty: 1 Piece
OR
Reach Us At +91-9243011081

Sanwa HG561H - 500 V Hybrid M Clamp Meter

Price

Available on Request
Delivery * Free delivery above Rs. 1000
* COD payment upto Rs. 5000
* 7 days easy replacement policy
* Bulk orders are shipped through surface and therefore might take more than 10 days for delivery

Check

Please enter pincode.
Services

Dispatch in 2-3 days

Standard SD Replacement Policy

100% Authentic and Genuine Products. Secure and Safe Payments.

NA

NA

Description
  • The insulation resistance is equipped with a 7 range, so you can set only the voltage to use it. Comes with DC voltage, AC voltage, and automatic detection function. ?M Omega display in both numerical and LED level meter. Decimal positions are fixed to prevent misreading. Equipped with a probe that can be measured directly from the hole in the breaker cover. Equipped with an LCD backlight and an LED light that illuminates the measuring site
  • Equipment maintenance Measure current for distribution boards, etc
  • AC Voltage: 600 V; Rated Voltage (V/M Omega): 15/21, 25/21, 50/21, 100/110, 125/110, 250/110, 500/110; Minimum Display (M Omega): 0.1; Resistance (Omega): 99.9 k; Weight: 230 g
  • Dimensions (W x D x H): 3.6 x 1.1 x 5.5 inches (91 x 29 x 139 mm); Power Supply: AAA alkaline batteries (LR03 x 4 (included); Maximum display: 3999 counts; DC / AC voltage (V): 600 (automatic detecting); Conduction check: buzzer sound under 30 Omega; JIS C13 compliant
  • Measuring probe red x 1, alligator clip x 1, carrying case, manual (English language not guaranteed)
Product Specifications

GENERAL

AC Voltage Range:
600 V
Brand:
Sanwa
Country of Origin:
Japan
Counts:
3999
DC Voltage Range:
600 V
Dimensions:
29x91x139 mm
Display:
LCD
Model:
HG561H
Resistance:
99.9 k
Weight:
230 Grams
