Samsonic UTG 111 - Ultrasonic Thickness Gauge


Available on Request
Quantity
Minimum Order Quantity: 1 unit(s) Packing Qty: 1 Piece
OR
Reach Us At +91-9243011081

Samsonic UTG 111 - Ultrasonic Thickness Gauge

Price

Available on Request
Delivery * Free delivery above Rs. 1000
* COD payment upto Rs. 5000
* 7 days easy replacement policy
* Bulk orders are shipped through surface and therefore might take more than 10 days for delivery

Check

Please enter pincode.
Services

Dispatch in 2-3 Business Days

Standard SD Replacement Policy

100% Authentic and Genuine Products. Secure and Safe Payments.

NA

NA

Description
  • It Is Based on The Same Operating Principles As SONAR, The Instrument Is Capable of Measuring the Thickness of Various Material with Accuracy as High As 0.1/0.001mm. These Gauges Are Capable of Performing Measurements on A Wide Range of Material Including Metals, Plastic, Ceramics, Composites, Epoxies, Glass and Other Ultrasonic Wave Well-Conductive Material. The Transducer Modes of Gauge Are Available for Special Application Including for Coarse Grain Material and High Temperature.
  • Two Point Calibration Function
  • Two Work Modes: Single Point Mode and Coupling Status
  • Coupling Status Indicator Showing the Coupling Status
  • Auto Sleep and Auto Power Off Function to Conserve Battery Life
  • Memory For 20 Files (Up To 99 Values for Each File) Of Stored Values
Product Specifications

GENERAL

Accuracy:
+/- (0.5 Percent Thickness+0.04)mm
Brand:
Samsonic
Communication:
RS 232 Serial Port
Country of Origin:
India/China
Dimension:
150x74x32 mm
Display:
4.5 Digits LCD With EL Backlight
Measuring Range:
0.75-300 mm (Steel)
Model:
UTG 111
Power:
Two AA Size 1.5 Volt Alkaline Batteries, 100 Hours Typical Operating Time (El Back Light Off)
Resolution:
0.01 mm
Sound Velocity Range:
1000-9999 M/S
