Battery Type:
Rechargeable Li on
CE Compliance:
EMC Directive: 2004/108/EC. R&TTE directive: 1999/5/EC.ATEX directive: 94/9/EC
Display:
Monochrome graphical LCD Display (128 x 160) with backlighting.
Dust and Water Resistance:
IP 65 (pumped) IP 67 (diffusion) ingress protection rating
EMI/RFI:
No effect when exposed to 0.43mW/cm2 RF interference from a 5 watt transmitter at 12 inch (30 cm)
Humidity:
0 Percentage to 95 Percentage relative humidity (non condensing)
Keypad Buttons:
3 operation and programming keys (Mode, Y/+, and N/-
Operating temperature:
- 4 Degree to 122 Degree F (-20 Degree to 50 Degree Celsius
Performance Test:
LEL CSA C22.2 No. 152 ISA-12.13.01
Pumped Model Size:
7.6 Inch x 3.8 Inch x 2.6 Inch, 193 x 96.5 x 66 mm
Pumped Model Weight:
31 oz, 800 grm
Sensor:
electrochemical sensors for toxic gases and oxygen, combustible LEL and NDIR sensors and CO2 NDIR sensor
Warranty:
RAE Systems Standard Warranty
Wireless Frequency:
ISM License free bands
