Area of Application:
Sprinklers, Domestic Applications, Nurseries, Hotels, Industries, Gardens & Fountains, Agricultural Irrigation, Fire Fighting, Mines, Drip Irrigation, Public Water Supply, Ponds
Duty Type:
Continious (S1)
Head vs Discharge at 0.75 KW, 1.00 HP:
85 Meters: 0 LPM, 81 Meters: 17 LPM, 80 Meters: 20 LPM, 70 Meters: 30 LPM, 66 Meters: 40 LPM, 60 Meters: 50 LPM, 53 Meters: 60 LPM, 45 Meters: 70 LPM, 37 Meters: 80 LPM
Middle Bearing:
Bronze / Carbon Graphite
Motor Body:
Stainless Steel
Pumping Medium:
Clean Water free from soliids & Fibre free, Chemically and Mechanically Non-Aggressive
Special Features:
Designed for wide voltage fluctuations, Rewindable motor portion, Easy maintenance, High operating efficiency, Dynamically Balanced Rotors & Impellers ensure long life, Water lubricated bearings, Smooth and Noiseless operations, Low friction carbon thrust
Specific Gravity:
1.004 Max
Temperature:
< 35 Degree Centigrade
Thrust Bearing:
SS / Carbon Graphite
