Buy Mitutoyo 3058S 19 - 50 mm Dial Indicator Online

Mitutoyo 3058S - 0-100mm Large Dial Face Dial Indicator


Available on Request
Quantity
Minimum Order Quantity: 1 unit(s) Packing Qty: 1 piece
OR
Reach Us At +91-9243011081

Mitutoyo 3058S - 0-100mm Large Dial Face Dial Indicator

Price

Available on Request
Delivery * Free delivery above Rs. 1000
* COD payment upto Rs. 5000
* 7 days easy replacement policy
* Bulk orders are shipped through surface and therefore might take more than 10 days for delivery

Check

Please enter pincode.
Services

Dispatch in 2-3 Business Days

Standard SD Replacement Policy

100% Authentic and Genuine Products. Secure and Safe Payments.

NA

NA

Description

Features:

  • Standard 0.01 mm graduation dial gauges having an outer frame with an outside diameter of 57 mm. All types come with limit pins and an outer frame clamp as standard.
  • The outer clamp and lifting lever (optional) can be attached to either the right or left side. These parts can be easily installed and removed without tools.
  • Secured adhesion between the outer frame and crystal as well as the use of an O-ring ensure countermeasures against water and oil permeation via the front face.
  • The stem spindle is made of high-strength quench-hardened stainless steel which resists strenuous use.
  • A carbide contact point is used.
  • The grand gear uses stainless steel that is resistant to wear and deformation.
  • Application of a hard coating on the surface of the crystal makes the gauge highly scratch- and chemical-resistant
Product Specifications

GENERAL

Accuracy:
0.030 mm
Brand:
Mitutoyo
Country of Origin:
Japan
Dial Reading:
0-100 mm
Graduation:
0.01 mm
Measuring Force:
3.0N or less
Model:
3058S-19
Range:
50 mm/1 mm
