Buy Mextech DIT 2520 - 2500 V Insulation Tester Online

Mextech DIT 2520 - 2500 V Insulation Tester


Available on Request
Quantity
Minimum Order Quantity: 1 unit(s) Packing Qty: 1 Piece
OR
Reach Us At +91-9243011081

Mextech DIT 2520 - 2500 V Insulation Tester

Price

Available on Request
Delivery * Free delivery above Rs. 1000
* COD payment upto Rs. 5000
* 7 days easy replacement policy
* Bulk orders are shipped through surface and therefore might take more than 10 days for delivery

Check

Please enter pincode.
Services

Dispatch in 1-2 Business Days

Standard SD Replacement Policy

100% Authentic and Genuine Products. Secure and Safe Payments.

NA

NA

Description
  • 3.75 digits jumbo LCD display with unit annunciator and backlit; Maximum reading 3999; Test of insulation resistance at 500 V or 1000 V 2500 V with high driving capacity of ≥ 15mA; Dual display of the testing voltage and insulation value simultaneously; Data hold; Auto ranging multimeter; User panel calibration; Overload protection; Safety as per IEC1010-1 Cat.II 1000 V.
  • Digital Multimeter : DCV: 400m/4/40/400/1000V, +/- 0.5 percent; ACV: 4/40/400/700V, +/- 0.8 percent; DCA: 40m/400mA, +/- 0.8 percent; ACA: 40m/400mA, +/- 1 percent; OHM: 400/4K/40K/400K/4M/40MOhm, +/- 0.8 percent; CAP: 40n/400n/4 Micro /40 Micro F, +/- 3 percent; Frequency: 40/400/4K/40K/400K/4MHz, +/- 0.5 percent; Audible continuity buzzer: <380Ohm; Battery: 1.5V x 6, AA size.
  • Short circuit output greater than or equal to 15mA; Measuring time 1/2/10 minute selectable.
Product Specifications

GENERAL

Battery:
1.5 Vx6, AA size
Brand:
Mextech
Country of Origin:
China
DCA:
40 m/400 mA, +/- 0.8 Percent
DCV:
400 m/4/40/400/1000 V, +/- 0.5 percent
Frequency:
40/400/4 K/40 K/400 K/4 MHz, +/- 0.5 Percent
Height:
156 mm
Length:
170 mm
Measurement accuracy:
200 Micro Ohm - 4 Giga Ohm: +/-5 Percent rdg+/-5
Model:
DIT 2520
