Metrix Plus - 1000 V Analog Multimeter is a metric tool that combines several measuring parameters into a single unit. The 1000 V Analog Multimeter consists of an Analog display with scale and indicator, a radial or a regulator, two knobs for test leads and probe tips, power and operating buttons and batteries. The Analogue Multimeter's main functions include measuring AC and DC voltage, measuring the resistance, electrical capacitance and inductance, and measuring Alternating Current and Direct Current value.
Product Specifications:
AC voltage: 10 V, 50 V, 250 V, 1000 V
Brand: Metrix Plus
Direct current: 2.5, 25, 250 mA, 10 A
DC voltage: 2.5 V, 10 V, 50 V, 250 V, 1000 V
Model: HC-260TR
Resistance: 20 Ohm, 200 Ohm, 20 k Ohm, 200 K Ohm
Ranges: 2.5, 10, 50, 250,1000V
Sensitivity: 20.000 ohms/ volt
Accuracy: ±:3% DC
Potential Drop: 0.25V on all ranges
D8 RANGES: -10 DB to +22DB on 10V AC range
