Metrix Plus- 600 V Digital Insulation Tester is a metric tool used to measure the amount of resistance in the electronic circuits and wires. The 600 V Digital Insulation Tester consists of components such as a digital display of 4 digits, the power and operating buttons, test leads with probe tips and insulated wires, a regulator to set the voltage and power batteries. The Digital Insulation Tester instrument measures voltages > 25 V to 600 V AC/DC and are ideal for heavy-duty use. The 600 V digital insulation tester can test AC Voltage 1V-750V; the AC Voltage frequency is 40Hz-70Hz.
Product Specifications:
AC voltage: 30 to 600 V
Brand: Metrix Plus
DC voltage: 30 to 600 V
Display: Extra Large backlight LCD screen Display Counts: 999
Model: DIT 3125A
Resolution: 1 V
Operating Temperature: 0 - 50 ℃
Storage Temperature: -20 - 70 ℃
Auto Power Off
Weight: 1027 g
Overload Protect: AC 1200V/10Sec
