Metravi TM 6002 Battery Impedance Tester is the perfect tool to check a battery’s internal resistance, voltage, circuit, and temperature with 9999 memory and PC interface cable and software. This Metravi Battery Impedance Tester has DC Current measuring range of 0.6 A – 700 A DC, Resistance measuring range of 10 micro Ohm – 40 Ohm, and Voltage measuring range of 1mV – 40 V. It applies the AC Four terminal method to measure the internal impedance. It eliminates contact impedance and lead impedance to get precise and accurate results. This Impedance Tester comes with a multi-display LCD to display internal impedance, voltage and clock. It has 99 sets of composite comparator function and pin type leads for easy contact of the battery electrode. This tester can log data up to 9999 sets. It comes with a large backlight display that provides better visibility and improves accuracy. The compact design makes it easy for users to carry the product with them at all times.
Product Attributes:
• DC Current measuring range of 0.6 A – 700 A DC
• Resistance measuring range of 10 micro Ohm – 40 Ohm
• Voltage measuring range of 1mV – 40 V
• AC Four terminal method to measure internal impedance
• Multi-display LCD to display
• 99 sets of composite comparator function
• Pin type leads
• Data logging up to 9999 sets
• Large backlight display
Benefits:
• Accurate readings
• Easy contact of battery electrode
• Compact design
• Better visibility
• Easy use and transportation
