AC Voltage Range:
0.1 -750V, Accuracy - +/-1.5 Percent rdg+/-3dgt, Resolution - 0.1V
Accuracy:
+/-3 Percent Rdg+/-5Dgt
Basic Conditions:
23°C+/-5°C, Below 75 Percent Rh
Capacitance Test:
10Nf - 50Uf, Accuracy - +/-10 Percent rdg+/-5dgt, Resolution - 10nF
DC Current Measurement:
0.01Na- 6Ma, Accuracy - +/-5.0 Percent rdg+/-5dgt, Resolution - 0.01nA
DC Voltage Range:
0.1 -1000V, Accuracy - +/-1.5 Percent rdg+/-3dgt, Resolution - 0.1V
Functions:
Insulation Resistance Test, Voltage Test, Current Test, Capacitance Test
Insulation Resistance Range(G Ohm):
0.01MOhm-10TOhm, Accuracy - +/-3 Percent rdg+/-5dgt, Resolution - 0.01M Ohm
Output Short-circuit Current:
?6Ma
Resistance Limit Range:
0.01MOhm-10TOhm
