MECO MC981 - 0 to 2000 M Ohm, 1000V Analog Insulation Tester


Available on Request
Quantity
Minimum Order Quantity: 1 unit(s) Packing Qty: 1 Piece
OR
Reach Us At +91-9243011081

MECO MC981 - 0 to 2000 M Ohm, 1000V Analog Insulation Tester

Price

Available on Request
Delivery * Free delivery above Rs. 1000
* COD payment upto Rs. 5000
* 7 days easy replacement policy
* Bulk orders are shipped through surface and therefore might take more than 10 days for delivery

Check

Please enter pincode.
Services

Dispatch in 1-2 Business Days

Standard SD Replacement Policy

100% Authentic and Genuine Products. Secure and Safe Payments.

NA

NA

Description

Features:

  • Single Person Push Button Operation
  • High Accuracy ±5% of Indicated Value in Effective Range
  • Scale Length : 80mm (approx.)
  • Terminal Voltage :>85% of Rated Voltage for Insulation Resistance
  • Measurement from 10% to 100% of the Insulation Resistance Range
  • ABS Resin Yellow Case with Polycarbonate Meter Front Cover
  • Meets Requirement of IEC1010, Installation Category II, 1000VPhase Earth
  • Designed to Generally Confirm to IS 10656-1983
  • 7 Models with various Voltage & M Ohm Ranges

Applications:

  • Ideal for Insulation Resistance Measurement of
  • Electrical Equipment (Motors, Transformers, Machines, etc.)
  • Cables for Communication Networks
  • Industrial, Commercial & Residential Installations
  • Electrical Cables for Distribution Networks
  • House Hold Appliances (Washing Machines, Mixer, Toaster, etc.)

Accessories:

  • Pair of Crocodile / Alligator Test Leads (Red & Black) x 1, Carrying Case x 1, 1.5V AA Batteries x 6 (Fitted In)

Free online free online HTML editor lets you easily help edit content for your websites.

Product Specifications

GENERAL

Accuracy:
+/- 5 Percentage of Indicated Value at 27 Degree C +/-5 Degree C
Brand:
MECO
Country of Origin:
India
Dielectric Strength:
3.5 KV At 50 Hz For 1 Min Between Internal Terminal And Case
Dimensions:
144.5x95x72.5 mm (approx.)
Insulation Resistance:
More than 50 M Ohm at 500V Between Circuit and Case
Low Battery:
When Battery Voltage Drops Below Operating Voltage, Pointer Cannot Reach Zero After Shorting The Output Terminals
Model:
MC 981
Operating temperature:
0 Degree to 50 Degree C
Power:
9V (6 x 1.5V AA) Battery
Product Type:
Analog Insulation Tester
Relative humidity:
80 Percentage Maximum
Resistance:
0 - 2000 M Ohms
Standard Accessories:
Pair of Crocodile / Alligator Test Leads (Red And Black) x 1, Carrying Case x 1, 1.5V AA Batteries x 6 (Fitted - In)
Standards:
IS 10656 - 1983, IEC 61010, Installation Catagory II, 1000V Phase Earth
Storage Temperature:
- 10 Degree C to 60 Degree C
Test Voltage DC:
1000V
Weight:
438.6 Grams Including Battery (approx.)
