Buy MECO MC906 - 0 to 200 M Ohms, 1000V Analog Insulation Tester Online

MECO MC906 - 0 to 200 M Ohms, 1000V Analog Insulation Tester


Available on Request
Quantity
Minimum Order Quantity: 1 unit(s) Packing Qty: 1 Piece
OR
Reach Us At +91-9243011081

MECO MC906 - 0 to 200 M Ohms, 1000V Analog Insulation Tester

Price

Available on Request
Delivery * Free delivery above Rs. 1000
* COD payment upto Rs. 5000
* 7 days easy replacement policy
* Bulk orders are shipped through surface and therefore might take more than 10 days for delivery

Check

Please enter pincode.
Services

Dispatch in 1-2 Business Days

Standard SD Replacement Policy

100% Authentic and Genuine Products. Secure and Safe Payments.

NA

NA

Description

Built by Meco, a renowned Testing & Measuring Equipment’s of electrical products manufacturing company certified for Electrical Power Testing of tools and products. It provides a variety of Insulation Testers which are ideal for measuring insulation resistance of electrical components. The MECO MC906 is reliable and provides accurate data to prevent short circuits and electric shocks. It has an insulation range starting from 10% and limits at 100%. Made with quality assured materials the MECO Analog Insulation Tester is the best choice for checking the effectiveness of insulation resistance for any electrical product. It is built with polycarbonate materials which helps in impact resistance and provides better safety than most other insulation testers

Product Attributes:
High accuracy of +/-5%
Measures 10-100% of insulation range
Push button start
Polycarbonate resin yellow case

Benefits:
80mm scale length
Resistance of 0-200 M Ohms
Dielectric strength of 3.5kV at 50Hz per min
Approximate weight of 440gm including the battery

Product Specifications

GENERAL

Accuracy:
+/- 5 Percentage of Indicated Value at 27 Degree C +/-5 Degree C
Brand:
MECO
Country of Origin:
India
Dielectric Strength:
3.5 KV At 50 Hz For 1 Min Between Internal Terminal And Case
Dimensions:
144.5x95x72.5mm (approx.)
Insulation Resistance:
More than 50 M Ohm at 500V Between Circuit and Case
Low Battery:
When Battery Voltage Drops Below Operating Voltage, Pointer Cannot Reach Zero After Shorting The Output Terminals
Model:
MC 906
Operating temperature:
0 Degree to 50 Degree C
Power:
9V (6 x 1.5V AA) Battery
Product Type:
Analog Insulation Tester
Relative humidity:
80 Percentage Maximum
Resistance:
0 - 200 M Ohms
Standard Accessories:
Pair of Crocodile / Alligator Test Leads (Red And Black) x 1, Carrying Case x 1, 1.5V AA Batteries x 6 (Fitted - In)
Standards:
IS 10656 - 1983, IEC 61010, Installation Catagory II, 1000V Phase Earth
Storage Temperature:
- 10 Degree C to 60 Degree C
Test Voltage DC:
1000V
Weight:
438.6 Grams Including Battery (approx.)
