Buy MECO MC901 - 0 to 20 M Ohm, 100V Analog Insulation Tester Online
OUT OF STOCK

MECO MC901 - 0 to 20 M Ohm, 100V Analog Insulation Tester


Available on Request
Quantity
Minimum Order Quantity: 1 unit(s) Packing Qty: 1 Piece
OR
Reach Us At +91-9243011081

MECO MC901 - 0 to 20 M Ohm, 100V Analog Insulation Tester

Price

Available on Request
Delivery * Free delivery above Rs. 1000
* COD payment upto Rs. 5000
* 7 days easy replacement policy
* Bulk orders are shipped through surface and therefore might take more than 10 days for delivery

Check

Please enter pincode.
Services

Dispatch in 1-2 Business Days

Standard SD Replacement Policy

100% Authentic and Genuine Products. Secure and Safe Payments.

NA

NA

Description

MECO MC901 - Analog Insulation Tester is a high accuracy Analog Insulation Tester which shows nothing but effective results. This electrical power testing tool is ideal for a huge range of purposes. It can be used for household purposes and for electrical equipment. It comes with push-button operation and can measure voltage in the range of 10Percent to 100Percent insulation resistance range. MECO MC901 - Analog Insulation Tester meets industry standards and the best device to serve your purpose. It comes with ABS Resin Yellow Case, Pair of Crocodile / Alligator Test Leads and 1.5V AA Batteries accessories.

Features:

  • Precise measurements with +/- 5 Percent variations
  • IS 10656 - 1983, CAT II 1000 V
  • Operating temperature 0 Deg to 50 Deg C
  • Storage temperature - 10 Deg C to 60 Deg C
  • Resistance 0 - 20 M Ohms
  • 50M Ohm at 500V
  • Testing voltage 100 V
  • 9V battery

Benefits:

  • User-friendly
  • Precise and accurate
  • Effective to be used for motors, machines and home appliances
Product Specifications

GENERAL

Accuracy:
+/- 5 Percentage of Indicated Value at 27 Degree C +/-5 Degree C
Brand:
MECO
Country of Origin:
India
Dielectric Strength:
3.5 KV At 50 Hz For 1 Min Between Internal Terminal And Case
Dimensions:
144.5x95x72.5 mm (approx.)
Insulation Resistance:
More than 50 M Ohm at 500V Between Circuit and Case
Low Battery:
When Battery Voltage Drops Below Operating Voltage, Pointer Cannot Reach Zero After Shorting The Output Terminals
Model:
MC 901
Operating temperature:
0 Degree to 50 Degree C
Power:
9V (6 x 1.5V AA) Battery
Product Type:
Analog Insulation Tester
Relative humidity:
80 Percentage Maximum
Resistance:
0 - 20 M Ohms
Standard Accessories:
Pair of Crocodile / Alligator Test Leads (Red And Black) x 1, Carrying Case x 1, 1.5V AA Batteries x 6 (Fitted - In)
Standards:
IS 10656 - 1983, IEC 61010, Installation Catagory II, 1000V Phase Earth
Storage Temperature:
- 10 Degree C to 60 Degree C
Test Voltage DC:
100V
Weight:
438.6 Grams Including Battery (approx.)
