Buy MECO 7002 - 1-120 MOhm Milli Ohm Meter Online

MECO 7002 - 1-120 MOhm Milli Ohm Meter


Available on Request
Quantity
Minimum Order Quantity: 1 unit(s) Packing Qty: 1 Piece
OR
Reach Us At +91-9243011081

MECO 7002 - 1-120 MOhm Milli Ohm Meter

Price

Available on Request
Delivery * Free delivery above Rs. 1000
* COD payment upto Rs. 5000
* 7 days easy replacement policy
* Bulk orders are shipped through surface and therefore might take more than 10 days for delivery

Check

Please enter pincode.
Services

Dispatch in 1-2 Business Days

Standard SD Replacement Policy

100% Authentic and Genuine Products. Secure and Safe Payments.

NA

NA

Description

Features :

  • Basic Accuracy 0.25%
  • Max. Test Current : 5A (120mV)
  • Manual or Auto Range
  • Four Terminal Kelvin Measurement
  • 6 Ranges with 1mV Best Resolution
  • Measurement of Resistive and Inductive Materials
  • Setting for HI, LO & PASS Readings
  • Memory of 3000 Measurements Data
  • Programmable HI-LO Alarm with memory of 20 Data
  • Large LCD with Backlight & HOLD Function
  • Low Power Consumption
  • Battery Operated with AC Adaptor
  • Low Battery (Voltage) Alarm
  • LED indication for Invalid Resistance Measurement
  • Cable Length Measurement in feet & meters
  • User Interface Software for PC Communication via
  • RS232C (to USB Bridge) cable
  • Built-in Battery Changing Circuit & Calender Clock
Product Specifications

GENERAL

AC Adaptor:
Input 110V or 220V AC, Output DC 15V/1 to 3A
Battery Charging time:
10 hrs
Brand:
MECO
Country of Origin:
India
Dimension:
260x158x70 mm (approx.)
Display:
4 5/6 Digit LCD Display With Backlight
Electrical Specification:
23 Degree +/- 5 Percent
Environment:
Operating - 0 to 50 Degree C Greater Than or Equal to 85 Percentage RH, Storage: - 20 to 60 Degree C Greater Than or Equal to 75 Percentage RH
Max. Test Current:
5A (120 mOhm)
Model:
7002
Product Type:
Milli Ohm Meter
Resistance:
Manual Range - 1 to 8, 5 to 32, 10 to 120 MOhm, Auto Range - 1 to 8, 8 to 120 m Ohm
Resolution:
Manual Range -10 Micro ohm, Auto Range - 1 to 10 MOhm
Standard Accessories:
Users Manual x 1, Software Manual x 1, Software CD x1, RS232C (to USB Bridge) Cable x1, AC Adaptor x1, 11.1V AA Rechargeable Battery (1600 mAh) x 1, 1 Set of Kelvin Clips (2 Clips), Carrying Bag
Weight:
1125 Grams Battery Included
