The Master Metrology - 3/16 inch dia, 24 BSW Thread Plug Gauge measuring less than 100mm is a taper shank thread plug gauge. The 3/16 inch dia, 24 BSW Thread Plug Gauge is a double screw thread plug gauge. It is easy to operate and maintain, thus giving out a superior performance. The Thread plug gauge is a tool to measure the correctness of internal thread size. For measuring the 24 BSW Thread Plug Gauge, clean sheets and impurities must be cleaned before the thread plug gauge. If the measured thread is positive, then the thumb and forefinger can rotate the ring gauge so that the thread in the free state can be determined according to the full length of the thread. While using the Plug Gauge, it is important to pay attention to the test thread tolerance class and deviation code and the Gauge mark tolerance class. It is strictly forbidden to force screw threads into threads as cutting tools to avoid early wear and ensure the accuracy of measuring tools.
Product Specifications:
Brand: Master Metrology
Made In: India
Product: BSW Thread Plug Gauge
Hand Type: Right Hand
Pitch: 24 BSW
Size: 3/16 inch diameter
Thread Type: BSW Plug Thread
Key Features:
Precise
Economical
Accurate
