Mark 10 TTO2 - Series 2 Torque Gauge


Available on Request
Quantity
Minimum Order Quantity: 1 unit(s) Packing Qty: 1 Piece
OR
Reach Us At +91-9243011081

Mark 10 TTO2 - Series 2 Torque Gauge

Price

Available on Request
Delivery * Free delivery above Rs. 1000
* COD payment upto Rs. 5000
* 7 days easy replacement policy
* Bulk orders are shipped through surface and therefore might take more than 10 days for delivery

Check

Please enter pincode.
Services

Dispatch in 2-3 Business Days

Standard SD Replacement Policy

100% Authentic and Genuine Products. Secure and Safe Payments.

NA

NA

Description

Series TT02 Torque Tool Testers present a simple and accurate solution for testing manual, electric, and pneumatic torque screwdrivers, wrenches, and other tools. These testers are compact and rugged, suitable for production environments. A universal 3/8 and square receptacle accepts common bits and attachments. The TT02 captures peak torque in both measurement directions, and also calculates 1st and 2nd peaks, useful for click-type tools.

A blazingly fast sampling rate of 7,000 Hz and accuracy of +/- 0.3% produce reliable and consistent test results. The TT02 includes a range of sophisticated productivity-enhancing features, including USB, RS-232, Mitutoyo, and analog outputs, automatic data output/zeroing/data storage upon tool slip or click, memory storage for 1,000 readings, pass/fail indicators and outputs, and more. Password protection is provided to prevent unauthorized changes to settings and calibration.

Series TT02 testers include MESUR Lite data acquisition software. MESUR Lite tabulates continuous or single point data. Data stored in the TT02's memory can also be downloaded in bulk. One-click export to Excel allows for further data manipulation.

Product Specifications

GENERAL

Accuracy:
±0.3% of full scale
Battery Life:
Backlight on: up to 7 hours of continuous use, Backlight off: up to 24 hours of continuous use
Brand:
Mark 10
Configurable Settings:
1st/2nd peak, digital filters, outputs, automatic shutoff, default settings, key tones, backlight, audio alarms, passwords, calibration
Measurement Units:
ozFin, lbFin, kgFcm, Nm, Ncm
Model:
TT02
Output:
USB / RS-232: Configurable up to 115,200 baud, Mitutoyo (Digimatic): Serial BCD suitable for all Mitutoyo SPC-compatible devices, Analog: ±1 VDC, ±0.25% of full scale at capacity, General purpose: Three open drain outputs, one input, Set points: Three ope
Power:
AC or rechargeable battery. Multi-step low battery indicator is displayed, tester shuts off automatically when power is too low
Safe Overload:
150% of full scale- display shows “OVER” at 110% and above
Sampling Rate:
7,000 Hz
Weight:
2.6 kg
