Mark 10 TSB100 - 500 N Manual Test Stand


Available on Request
Quantity
Minimum Order Quantity: 1 unit(s) Packing Qty: 1 Piece
OR
Reach Us At +91-9243011081

Mark 10 TSB100 - 500 N Manual Test Stand

Price

Available on Request
Delivery * Free delivery above Rs. 1000
* COD payment upto Rs. 5000
* 7 days easy replacement policy
* Bulk orders are shipped through surface and therefore might take more than 10 days for delivery

Check

Please enter pincode.
Services

Dispatch in 2-3 Business Days

Standard SD Replacement Policy

100% Authentic and Genuine Products. Secure and Safe Payments.

NA

NA

Description

The lever operated Force Measurement Test Stand Model TSB100 is an economical solution for quick-action tensile testing and compression testing of up to 100 lbF (500 N) of force. Constructed of rugged components, this test stand is durable enough for the factory floor, yet precise enough for laboratory environments.

  • Maximum force: 100 lbF [500 N]
  • Maximum travel, with stops (optional): 3.75" [95 mm]
  • Maximum travel, without stops: 6" [150 mm]
  • Travel rate: 3" [76.2 mm]/lever revolution.
  • Compatible with all Mark-10 force gauges, accessories and grips.
  • Loading lever can be positioned in 30 deg increments for ease of operation.
  • Mounting holes for bench mounting.
  • Optional adjustable travel stops.
  • Precision ground rack for smooth precision motion.
  • Removable base plate with 25 #10-32 UNF holes for fixture mounting.
  • Low force friction brake.
Product Specifications

GENERAL

Brand:
Mark 10
Maximum Force:
100 lbF, 500 N
Maximum Travel with Stops:
3.75 inch, 95 mm
Model:
TSB100
Travel Rate:
3 inch, 76.2 mm /lever revolution
