Mark 10 ESM303 - 457 mm Motorized Tension or Compression Test Stand


Available on Request
Quantity
Minimum Order Quantity: 1 unit(s) Packing Qty: 1 Piece
OR
Reach Us At +91-9243011081

Mark 10 ESM303 - 457 mm Motorized Tension or Compression Test Stand

Price

Available on Request
Delivery * Free delivery above Rs. 1000
* COD payment upto Rs. 5000
* 7 days easy replacement policy
* Bulk orders are shipped through surface and therefore might take more than 10 days for delivery

Check

Please enter pincode.
Services

Dispatch in 2-3 Business Days

Standard SD Replacement Policy

100% Authentic and Genuine Products. Secure and Safe Payments.

NA

NA

Description

The ESM303 is a highly configurable single-column force tester for tension and compression measurement applications up to 300 lbF [1.5 kN], with a rugged design suitable for laboratory and production environments. Sample setup and fine positioning are a breeze with available Follow Me force-based positioning - using your hand as your guide, push and pull on the force gauge or load cell to move the crosshead at a variable rate of speed.

  • Selectable speed setting.
  • Upper and lower travel limit switches.
  • Adjustable, removal controller with intuitive menu navigation.
  • Password protection of test parameters.
  • Stepper motor-driven, producing smooth and quiet operation with no speed variation under load.
  • USB output of force vs. time or force vs. travel.
  • Compact footprint, suitable for crowded work benches.
  • Ergonomic design, with smart, clean cable management.
  • Integrated electronics assembly, easily removed and transported.
  • Adjustable mounting plate with T-slot base.
Product Specifications

GENERAL

Brand:
Mark 10
Limit Switch Repeatability:
0.001 in 0.03 mm
Load Capacity:
300 lbF (1.5 kN) @ up to 24 in/min (610 mm/min), 200 lbF (1 kN) @ >24 in/min (610 mm/min)
Maximum Travel Distance:
18.0 in, 457 mm
Model:
ESM303
Power:
Universal input 80-240 VAC, 50/60 Hz, 60W
Speed Range:
Standard: 0.5 - 13 in/min (13 - 330 mm/min), Optional: 0.02 - 45 in/min, 0.5 - 1,100 mm/min
Speed Setting Accuracy:
±0.2% of setting
Speed Variation with Load:
± 0% stepper motor driven
Travel Accuracy:
±0.002 in. per 10 in. ± 0.05 mm per 250 mm
Travel Resolution:
0.001 in / 0.02 mm
Weight:
25.6 kgs
