Description

Features:

  • The SM pumps are non self priming, horizontal, single stage centrifugal pumps.
  • Motor and pump are close coupled in a convenient and compact design for quick installation in limited space.
  • The pump is fitted with a maintenance free, mechanical shaft seal.
  • The pumps have axial suction port and radial discharge port.

Motor:

  • 2 pole induction motor, 50Hz (n=2900 RPM)
  • Single phase 230V +5% -15% with thermal protection.
  • Insulation class B.
  • Protection IP 44.
  • Constructed in accordance with IEC 34.
  • Direction of rotaion- Clockwise as seen from the motor rear end.

Applications:

  • For clean liquids without abrasives, which are non aggressive for the pump materials. (Solid content upto 0.2%)
  • For water supply.
  • For heating, cooling, air conditioning and circulation plants.
  • For civil and industrial applications.
  • As pressure boosting pumps for central water systems.
  • For irrigation.
  • For circulation plants.
  • For washing with a jet of water.

Operating Conditions:

  • Liquid temperature upto 90 degree C.
  • Ambient temperature upto 40 degree C.
  • Total suction lift upto 8 M.
  • Continous duty.
Product Specifications

GENERAL

Brand:
Lubi
Frequency:
50 Hz
Head vs Discharge at 0.50 HP:
33.5 M: 10 LPM, 24 M: 20 LPM, 19 M: 25 LPM, 15 M: 30 LPM, 10 M: 35 LPM, 5 M: 40 LPM
Max RPM:
2900 RPM
Model:
SM50
Number of Stages:
Single Stage
Phase:
Single
Pipe Length:
25x25 mm
Power:
0.50 HP, 0.37 kW
Series:
SM Series
Voltage:
230 V
