Lubi LSD 150125 - 65 kg LSD Series Suction Diffuser


Available on Request
Quantity
Minimum Order Quantity: 1 unit(s) Packing Qty: 1 Piece
OR
Reach Us At +91-9243011081

Lubi LSD 150125 - 65 kg LSD Series Suction Diffuser

Price

Available on Request
Delivery * Free delivery above Rs. 1000
* COD payment upto Rs. 5000
* 7 days easy replacement policy
* Bulk orders are shipped through surface and therefore might take more than 10 days for delivery

Check

Please enter pincode.
Services

Dispatch in 2-3 Business Days

Standard SD Replacement Policy

100% Authentic and Genuine Products. Secure and Safe Payments.

NA

NA

Description

The Lubi LSD suction diffuser is a device which directly mounts to the suction side of horizontal or vertical centrifugal pumps. It is designed to reduce space and installation cost by replacing a conventional 90 degree elbow, 'Y' strainer and flow stabilizing piping on the suction side of pump. It may also be used as a reducing elbow, should the suction piping be larger than the pump inlet.

Features:

  • 90 degree Elbow: Direct mounting to the suction flange of any pump with turn the piping 90 degree, this feature replacing a conventional elbow. In addition diffuser can be mount on a pump suction flange either horizontal or vertical position.
  • In-Strainer: The in-line strainer is a divided into a outer cylindrical start-up strainer and a star-shaped permanent strainer.
  • Guide Vanes: Flow stabilizing vanes on the outlet of suction diffuser allow the suction diffuser to bolt directly to the pump. This feature saves space and also reduces cost of a conventional long straight pipe.
  • Reducing Elbow: The suction diffuser connects same size piping to the pump suction, but can also connect to inlet piping one size larger than the pump suction, eliminating a reducing elbow.
Product Specifications

GENERAL

Brand:
Lubi
Flange Size:
Pump Side: 125 mm, 5 inch, System Side: 150 mm, 6 mm
Gross Weight:
65 kg
Model:
LSD 150125
Series:
LSD Series
Strainer Free Area:
114 Sq inch
