Flow rate:
1750 LPM at 7 Bar
Inlet Flange:
100 NB (4 inch) Raised Flange
Monitor Elevation:
+90 degree Above Horizontal - 45 degree below Horizontal
Monitor Movement:
Vertical Movement and Horizontal Movement: Geared Swivel Joint with Self Locking
Monitor Outlet:
21/2 inch water way with Jet Spray, Aqua Foam Nozzle with Pickup Tube
Monitor Rotation:
360 degree Continuous
Operating Pressure:
12 Bar (175 Psi)
Throw Range:
45 Meters, Projection Angle: 30 degree
