Buy Kusam Meco MM Series MMV - Full Function AC Voltage Meter Online
Kusam Meco

Kusam Meco MM Series MMV - Full Function AC Voltage Meter


Available on Request
Quantity
Minimum Order Quantity: 1 unit(s) Packing Qty: 1 Piece
OR
Reach Us At +91-9243011081
Kusam Meco

Kusam Meco MM Series MMV - Full Function AC Voltage Meter

Price

Available on Request
Delivery * Free delivery above Rs. 1000
* COD payment upto Rs. 5000
* 7 days easy replacement policy
* Bulk orders are shipped through surface and therefore might take more than 10 days for delivery

Check

Please enter pincode.
Services

Dispatch in 2-3 days

Standard SD Replacement Policy

100% Authentic and Genuine Products. Secure and Safe Payments.

NA

NA

Description

Kusum Meco full function AC voltage meter is designed so that they can measure the AC voltage under measurement. The AC voltage meter gives an accurate reading because of the high input resistance. The Kusum Meco AC voltage meter offers a high input impedance and draws significantly less current. The meter is compact and portable in shape and size and has high sensitivity. The Kusum Meco Ac voltage meter uses the repulsion between two charged plates to deflect a pointer attached to a spring. It can draw negligible current and works with either alternating or direct current. The voltage meter has a digital display that shows the result accurately and quickly.
Product specialisation
Country of Origin: India
DC current: 20 mA DC
Dead Band: 0~9999 Counts User Selectable.
Dielectric Strength: 2KV AC / Min Between Input / Power / Case.
Display Range: 0.56" High brightness RED LED 5 Digits, -19999~99999Counts
Key features
Digital display
Portable
Lightweight

Product Specifications

GENERAL

Accuracy:
0.15%FS+1 Counts. Avg. Typically at 23 DegreeC 13 Degree C . 0.25%FS+1 Counts. TRMS Typically at 23 Degree C 3 Degree C . Setting Function
Brand:
Kusam Meco
Country of Origin:
India
DC current:
0 — 20 mA DC
Dead Band:
0~9999 Counts User Selectable.
Dielectric Strength:
2KV AC / Min Between Input / Power / Case.
Digital output:
RS-485 Output, 1200,2400,4800,9600,19200 Baud Rate, User Selectable.
Display Range:
0.56" High brightness RED LED 5 Digits, -19999~99999Counts..
Impulse:
5 KV 1.2 x 50 uS, ANSI C37.90a / 1983.DIN IEC 255- 4.
Input Burden Input Over:
0.25 VA at 60 Hz
Input Frequency:
45~70 Hz
Input Over:
Normal AC 440V (Max. Ac 500V), Current Over 600V Continuous 1.2 KV 10sec/Hr
Model Number:
MM Series - MMV];(GENERAL) Output Response Time: S[<= 1 Sec. ( grogrammah1e per l00ms/unit )
Mounting:
Panel Flush Mounting.
Operating Condition:
-10°C +55°C 20 ~95% RH Non-Condensed
Outline Dimensions:
1/8 DIN 96W X 48H X 100D mm.
Output Protection:
Without Damage for Output Open or Short Circuit.
Power Supply:
AC or DC +/- 20%, 50 / 60Hz.
Setting Range:
-19999~99999 Counts User Selectable.
SPDT Capacity:
AC 120V 3A, DC 30V 3A.
Stability:
<= 0.2%/Year.
Storing Condition:
-40°C +75°C 20~95% RH Non-Condensed. Consumed Power
Temperature Coefficient:
<=60ppm / °C From 0 to 60 Degree C
Time Delay:
0~999 Sec. User Selectable.
