Description

The Kusam Meco - Full Function PT 100 Ohm Temperature Meter is a reliable instrument used to measure temperature. This Full Function PT 100 Ohm Temperature Meter has various settings for the most accurate readings. These Temperature Meters are primarily suitable for industrial applications.
Product Specifications:
Brand: Kusam Meco
Country of Origin: India
Consumed Power: 3VA , PF = 1
Dead Band: 0-9999 Counts.
Dielectric Strength: 2KV AC / Min Between Input / Power / Case.
Impulse: 5 KV 1.2x50 uS, ANSI C37.90a / 1983.DIN IEC 255- 4.
Model Number: MM Series - MMR];(GENERAL) Accuracy: S[0.15%FS +0.3 Degree C at 23-3 Degree C .
Mounting: Panel Flush Mounting.
Operating Condition: -10- 55 Degree C 20 95% RH Non-Condensed.
Outline Dimensions: 1/8 DIN 96W X 48H X 100D mm.
Power Supply: AC or DC î20%, 50 / 60Hz.
Setting Function: 4 Alarm Setting Function, Setting Function (Hi-Lo) User Selectable.
Setting Range: +/-19999 Counts
SPDT Capacity: AC 120V 5A , 250V 3A, DC 24V 3A.
Stability: <=0.2%/Year.
Storage Condition: -40 to +75°C 20-95% RH Non-Condensed.
Time Delay: 0-999 Sec. User Selectable.
Key Features:
Easy to operate
Allows customised settings
Best possible readings

Product Specifications

GENERAL

Brand:
Kusam Meco
Consumed Power:
3VA , PF = 1
Country of Origin:
India
Dead Band:
0-9999 Counts.
Dielectric Strength:
2KV AC / Min Between Input / Power / Case.
Impulse:
5 KV 1.2x50 uS, ANSI C37.90a / 1983.DIN IEC 255- 4.
Model Number:
MM Series - MMR];(GENERAL) Accuracy: S[0.15%FS +0.3 Degree C at 23-3 Degree C .
Mounting:
Panel Flush Mounting.
Operating Condition:
-10- 55 Degree C 20 95% RH Non-Condensed.
Outline Dimensions:
1/8 DIN 96W X 48H X 100D mm.
Power Supply:
AC or DC î20%, 50 / 60Hz.
Setting Function:
4 Alarm Setting Function, Setting Function (Hi-Lo) User Selectable.
Setting Range:
+/-19999 Counts
SPDT Capacity:
AC 120V 5A , 250V 3A, DC 24V 3A.
Stability:
<=0.2%/Year.
Storage Condition:
-40 to +75°C 20-95% RH Non-Condensed.
Time Delay:
0-999 Sec. User Selectable.
