The Kusam Meco – 280x183 mm Microprocessor Multifunction TRMS Power Meter with 12 Displays is a digital, Microprocessor based TRMS meter suitable for domestic and industrial spaces. The 280x183 mm Microprocessor Multifunction TRMS Power Meter with 12 Displays is designed like a panel that can be flush-mounted. The Microprocessor Multifunction TRMS Power Meter with 12 Displays monitors 12 parameters in real-time simultaneously. The TRMS Power Meter with 12 Displays can retain measurements dating back to up to 10 years. The TRMS Power Meter is designed according to DIN IEC 688 standards and has a user-friendly interface.
Product Specifications:
Manufactured by: Kusam Medco
Country of Origin: India
Product Code: KM 8100 A
Product: Multifunction TRMS Power Meter
Display: 12
Type: Microprocessor-based
Input Frequency: 45 Hz - 70 Hz
Input Voltage Over Range: Voltage- 200% Continuous, 300% of rating for 10 sec
Input Current Range: Current - 110 % for rating. 0 - 1A or 0 - 5A, - C. T. Ratio Programmable upto 9999 / 5 A
Input Current Over Range: Current - 400% Continuous, 2000% of rating for 10 sec
DC Current: 0 - 20mA DC
Load resistance drive: output drive 10 VDC maximum
DC Voltage: 0 -10 V DC
Load resistance drive: Output drive 5mA maximum
Output Response Time : <1 Sec
Key Features:
RS485 Output available
Selectable MODBUS RTU mode
