Kusam Meco KM 6310 IN - 10 kV Digital High Voltage Insulation Resistance Tester


Available on Request
Quantity
Minimum Order Quantity: 1 unit(s) Packing Qty: 1 Piece
OR
Reach Us At +91-9243011081

Kusam Meco KM 6310 IN - 10 kV Digital High Voltage Insulation Resistance Tester

Price

Available on Request
Delivery * Free delivery above Rs. 1000
* COD payment upto Rs. 5000
* 7 days easy replacement policy
* Bulk orders are shipped through surface and therefore might take more than 10 days for delivery

Check

Please enter pincode.
Services

Dispatch in 2-3 Business Days

Standard SD Replacement Policy

100% Authentic and Genuine Products. Secure and Safe Payments.

NA

NA

Description
  • 2 Lines x 16 characters LCD
  • Microprocessor-controlled.
  • Tests insulation resistance up to 20 T Ohms.
  • 4 Insulation test voltages : 1000V, 2500V, 5000V, 10000V
  • AC / DC Voltmeter (30~600V).
  • Short-circuit current up to 5mA.
  • PI (Polarization Index) indication.
  • DAR (Dielectric Absorption Ratio) indication.
  • Auto-ranging on all insulation ranges.
  • Optical USB to RS-232 data transmission.
  • Well isolated from contact.
  • Well protected from surges.
  • 2 built-in optical LEDs for data transfer.
  • Visual and audio warning of external voltage presence.
  • Auto-hold function to freeze reading
  • Overload protection
  • Adjustable testing duration : 1-30 minutes.
  • Internal memory for data storage.
  • Displays testing duration for insulation measurement.
  • Auto-off function.
Product Specifications

GENERAL

AC voltage:
30-600 V
Brand:
Kusam Meco
Country of Origin:
China
Current:
0.5 nA-0.55 mA
DC voltage:
30-600 V
Dimensions:
330x260x160 mm
Model:
KM 6310 IN
PI:
Yes
Power Source:
1.5V C Type × 8 Alkaline Batteries
Short Circuit Current:
upto 5 mA
Test Insulation Resistance:
upto 20 T Ohms
Test Insulation Voltage:
10 kV
Weight:
4284 grams
