Microscope Specifications Observation head Trinocular observation head inclined at 45°, rotateable through 360°, interpupilary distance adjustment ring 55-75mm, dioptric adjustment ring on the left ocular having adjustable dioptric scale with trinocular tube for photomicrographic/ camera attachments. Anti-Fungal Treated Observation Head. Main body All parts die casted to provide long life & good mechanical strength. Ergonomically Shaped and Corrosion Resistant, Anti Mould Treated. Focussing Precise and Separate coarse and fine focusing controls with ergonomically placed knobs on both directions. Friction/Hardness of Coaxial Knobs can be adjusted, Coarse Range: 24mm and Fine Precision Scale: 0.004mm. Magnification Configurations 40X, 60X, 100X, 150X, 400X, 600X, 1000X, 1500X Eyepiece High Eyepoint, WideField, Anti Fungus Treated Wide Field Eyepieces: WF10X (Field of Line: 18mm) Pair, WF15X Pair. Objectives CLARITY series DIN SEMI PLAN ACHROMATIC Objectives: 4X, 10X, 40X(S), 100X(O,S) Nosepiece Low Friction & Fully Parafocal Reverse (Backward) Quadruple Revolving Nosepiece Mechanical stage Co-axial low positioned mechanical x-y stage of size 120 x 125 mm with stage fine vernier graduation Condenser Abbe condenser n. A. 1. 25 having aspherical lens, adjustable iris diaphragm. Illumination Built in Super Bright LED Lamp, Variable Intensity Control with SMPS Based broad range 100V-220V Power Supply. Provided with Standard Indian Plug. USB CMOS MICROSCOPE CAMERA: • 5.0 megapixels with progressive scanning CMOS image sensor. • No compression, no interpolation. • Support still image capture(JPG,BMP) • Standard C-Mount makes connection to any microscope easy. Macro lens setups are also supported • Resolution: 2592X1944(8bit);480 Mibt/Sec,DC5V±5% • Pixel size: 2.2mmX2.2mm. • Frame Rate .8fps@2592X1944 30 fps@640 ×480 Auto White Balance. • Shutter Electronic10μs-32ms,Auto exposure • Operating Temp: 0°C ~ 60°C.
