The 2333 601 product of Insize External Dial Calliper Gauge is easy to carry, use, and adjust measuring instruments that measure between 40 and 60 mm of various components, like the measuring bores. This Insize 40 to 60 mm External Dial Calliper Gauge is supplied with a spring-loaded trigger that measures high-speed measurements with accuracy. Insize Dial Calliper Gauge is also used to measure the distance between two ends of an object with utmost precision.
Product Specification:
Arm Length of the Calliper Gauge: 80 mm.
Measuring Range of the Gauge: 40 to 60 mm.
Resolution of the Gauge: 0.01 mm or 0.005 inches.
Accuracy of the 40 to 60 mm External Dial Calliper Gauge: +/- 0.03 mm.
Tip Height, Width, and Radius of the Gauge: 25 mm, 6.5 mm, and R0.5 mm, respectively.
External Dial Calliper Gauge Readout Option: Dial.
