The HTC - 10 MHz Function Generator is a Function Generator with a frequency range between 0.1Hz-10 MHz. It is white and has 5 digits LED display with a dimension- 270x215x100 mm. The 10 MHz Function Generator’s output waveforms are Sine wave, Square wave, Triangle wave, Positive & Negative Sawtooth and positive & Negative Pulse with a square wavefront 0.1Hz-2MHz<100ns, 0.1Hz-10MHz<35ns. It comes with 3 regulators and Wave, Range, Run and Reset buttons and a one-year warranty.
Product Specifications:
Brand: HTC
Dimensions: 270x 215x 100 mm
Display: 5 Digit LED Display
Duty Cycle Adjustable: 20 - 80 %
Frequency of Output Signal: 0.2 Hz - 10 MHz
Model: FG-2010
Output Waveforms: Sine Wave, Square Wave, and Triangle Wave
Square-wave front: 0.1Hz - 2MHz <100ns, 0.1Hz - 10MHz <35ns
Sine wave Distortion: <1%(10Hz-100KHz)
Frequency Response: (0.1Hz-100KHz 00KHz) 1Hz - 10MHz <35ns Wave
Dimension- 270x215x10
