Buy HTC DM 92 - 0 to 750 V Digital Multimeter Online
HTC

HTC DM 92 - 0 to 750 V Digital Multimeter


Available on Request
Quantity
Minimum Order Quantity: 1 unit(s) Packing Qty: 1 Piece
OR
Reach Us At +91-9243011081
HTC

HTC DM 92 - 0 to 750 V Digital Multimeter

Price

Available on Request
Delivery * Free delivery above Rs. 1000
* COD payment upto Rs. 5000
* 7 days easy replacement policy
* Bulk orders are shipped through surface and therefore might take more than 10 days for delivery

Check

Please enter pincode.
Services

Dispatch in 1-2 Business Days

Standard SD Replacement Policy

100% Authentic and Genuine Products. Secure and Safe Payments.

NA

NA

Description

The HTC DM 92 is a standard multimeter from the manufacturer. It tests current, voltage, resistance, and capacitance. This 0 to 750 V digital multimeter has a large LCD display with manual range. There is no power-off under natural operation. This 3½ HTC digital multimeter provides protection for the user in all current and voltage ranges. The manufacturer provides a manual, holster and test leads with the HTC DM 92 multimeter. The product dimensions of this particular model of HTC digital multimeter is 185(H) x 93(W) x 35(D) mm.

Product Attributes:

• DC voltage of 200 mV - 1000 V accurate to ±0.5% + 3
• AC voltage of 2 V - 750 V accurate to ±0.8%+ 5
• DC current of 200 µA - 20 A accurate to ±0.8% + 3
• AC current of 20 mA - 20 A accurate to ±1.0% + 5
• Resistance range of 2 kΩ - 200 MΩ accurate to ±0.8% + 3
• Capacitance of 20 nF - 200 µF accurate to ±2.0% + 20

Benefits:

• Multi-functional
• Safety features
• Portable

Product Specifications

GENERAL

AC voltage:
0-750 V
AC Voltage Accuracy:
+/- 0.8 Percent, +5 Digits
Brand:
HTC
Country of Origin:
China
DC current:
200 mA-20 A
DC Current Accuracy:
+/- 0.8 Percent, +3 Digits
DC voltage:
200 mV-1000 V
DC Voltage Accuracy:
+/- 0.5 Percent, +3 Digits
Dimensions:
185x93x35 mm
Manufacturer Details:
HATCO Industries, Hazari House, 197-201 Cowasji Hormusji Street, Dhobi Talao, Kalbadevi, Mumbai – 400 002
Model:
DM-92
Packer Details:
HATCO Industries, Hazari House, 197-201 Cowasji Hormusji Street, Dhobi Talao, Kalbadevi, Mumbai – 400 002
Power:
9 V
Resistance:
0-200 M Ohm
Resistance Accuracy:
+/- 0.8 Percent, +3 Digits
