Applications:
Water transfer for Apartments, bungalows, farm-houses, building construction, gardening, fountains, overhead storage tanks, pressure booster systems, hotels, hospitals, industrial water circulation
Cable length and Size:
0.3 m & 1.0 sq. mm
Direction of Rotating:
Anti-clockwise when viewed from driving end
Dynamically Balanced Rotor:
Yes
High Suction with Self Priming:
up to 8 m
Low Power Consumption:
Yes
Maximum Working Pressure:
2.5 kg / cm2
Motor Body:
Graded Cast Iron
Motor Stator:
CRC Prossed grade stampings
Operating Water Temperature:
Ambient temperature
Suitable for:
Single phase supply
Voltage Operating Range:
200-280 V
Winding Type:
Copper winding
